NNC NNG6 series Solid State Relay Superior Performance for Industrial Applications

Brand Name : NNC

Model Number : NNG62-1/032F-38 1-4A

Certification : UL/TUV/CQC

Place of Origin : China

MOQ : 400pcs

Price : USD 1.72~1.78

Payment Terms : T/T, L/C

Supply Ability : 30k pcs 7 days

Delivery Time : 8-15days

Packaging Details : carton packing

Size : 29*12.6*28mm

Usage : Alternative type of the relay NNC69K 1NO model

Load current : 1-4A

Product name : Solid state relay

Type : Zero-crossing for AC output

Input voltage : 032F: 3-32VDC

Weight : ≈17g

Output voltage : 20: 12-200VDC; (Only for DC output) 22: 24-240VAC; 38: 24-440VAC; (Only for AC output)

Contact Now

NNG6 Series Solid State Relay

Features

2500VAC dielectric strength between input and output

Alternative type of the relay NNC69K 1NO model

PCB terminals/Plug-in socket terminals

Zero-crossing for AC output

Load current up to 4A

ORDERING INFORMATION

*Note: Not all combinations of current and voltage are available

NNG6 2 - 1 / 032F -38 4A ***

1.NNG6 series:

2.Terminals: 2: PCB terminals; 3: Plug-in terminals;

3.Load power supply: 0: DC Output; 1: AC Output;

4.Control voltage: 032F: 3-32V DC Input

5.Load voltage: 20: 12-200VDC; (Only for DC output) 22: 24-240VAC; 38: 24-440VAC; (Only for AC output)

6.Rated load current: 1-4A

7.Special code: ***: Customer Special Requirement; Blank: Standard

NNC NNG6 series Solid State Relay Superior Performance for Industrial Applications

Certificate

NNC NNG6 series Solid State Relay Superior Performance for Industrial Applications

Shipment & Packaging

Packing	Outer Box	Paper box(pcs)	400
	Dimension of the carton	CTN	400×265×355mm
	Weight	1pc	Approximate:17G
	Weight	1ctn	G.W:16KG N.W:15KG

NNC NNG6 series Solid State Relay Superior Performance for Industrial Applications

FAQ

Q1: Are you Factory?
A1:Yes,we focus on relay and micro switch more than 13years.

Q2: How do you control the products' quality?
A2: Auto inspection machine and manual testing together before packing.

Q3: What's your payment term?
A3:We usually accept T/T(30% deposit,the balance before delivery.)

Q4: Would you accept to use our logo?
A4: If you have good quantity,we can make OEM for you.

Q5: Can I get a sample for reference?
A5: We provide free samples for testing,you only need to pay the express cost.

Q6: What is your delivery time?
A6: Usually it takes 20-35 working days for production.

Q7: What is your warranty time of the products?
A7: 12-24 month
